Perlan 140 KS Wand mit Winkel Holz
- Extremely reliable corrosion protection for leaf weights up to 140 kg
- Precision ball bearings in the roller carriages offer very smooth sliding action
- Tested in accordance with EN 1670 Class 4 for external use or in extreme climatic conditions, such as swimming baths
Application Areas
- Corrosion-resistant fitting for exterior use
- Sliding shutters and shading systems
- Installation of fittings possible in combination with overhanging weather hood
- Single and multi-leaf sliding panel
- For wall installation
Installation situations in reference objects and videos
Perlan 140 Glass floor guide
Glass floor guide for sliding fitting systems © Studio BE / GEZE GmbH
Technical data
| Perlan 140 KS Wand mit Winkel Holz | |
| Leaf material | Wood |
| Leaf weight (max.) | 140 kg |
| Number of leaves | 1-leaf, 2-leaf |
| Leaf width (min.) | 500 mm |
| Leaf width (max.) | 1640 mm |
| Track geometry | straight |
| Type of installation | Wall |
| DIN direction | left / right |
